RaspberryPi の Ubuntu をヘッドレス起動する

RaspberryPi

Raspberry Pi 4 で Ubuntu 20.04 LTS をモニターやキーボード無しのヘッドレス起動した時のまとめです.

OS の準備

Raspberry Pi に電源を入れるまでは以下の通りの一般的な手順で行います.

  1. OSイメージ (Ubuntu) をダウンロード
  2. SDカードをSD Card Formatter でフォーマット
  3. balenaEtcher で Ubuntu を SDカードに 焼き込む

起動と接続

PC と Raspberry Pi を有線LANで繋いで,Raspberry Pi を起動します.
Raspberry Pi 用の Ubuntu はホスト名で接続できません
そのため, Raspberry Pi の IPアドレスを調べる必要があります.
今回は ipコマンドを使います.

Mac の場合は以下のコマンドで homebrew を使ってインストールできます.

brew install iproute2mac

次のコマンドで, PC に繋がっている端末のIPアドレスを表示します.

ip neigh

検索方法がわからなかったので,総当たりのつもりでしたが,今回はMacのIPアドレスがわかっていたので,それ以外に1つしか無かった192.168.4.2で確定できました.
力業になりますが, PC から Raspberry Pi 以外の端末を外したり, sshを総当たりすれば繋がると思います.

IP アドレスがわかったら,次のように ssh で接続します.

ssh ubuntu@[raspberry pi's ip address]

僕の場合は ssh ubuntu@192.168.4.2 でログインしました (pwはubuntu).
途中でパスワードを変更しろと言われるので変更します (もう一度ubuntuにしようとすると単純すぎると怒られます).

Botamochi-MacBook-Pro:~ botamochi$ ssh ubuntu@192.168.4.2
The authenticity of host '192.168.4.2 (192.168.4.2)' can't be established.
ECDSA key fingerprint is SHA256:****************************************.
Are you sure you want to continue connecting (yes/no)? yes
Warning: Permanently added '192.168.4.2' (ECDSA) to the list of known hosts.
ubuntu@192.168.4.2's password:
Warning: No xauth data; using fake authentication data for X11 forwarding.
X11 forwarding request failed on channel 0
You are required to change your password immediately (administrator enforced)
Welcome to Ubuntu 20.04 LTS (GNU/Linux 5.4.0-1008-raspi aarch64)

 * Documentation:  https://help.ubuntu.com
 * Management:     https://landscape.canonical.com
 * Support:        https://ubuntu.com/advantage

  System information as of Mon May 18 10:43:56 UTC 2020

  System load:  0.39              Temperature:           57.9 C
  Usage of /:   6.7% of 29.04GB   Processes:             133
  Memory usage: 7%                Users logged in:       0
  Swap usage:   0%                IPv4 address for eth0: 192.168.4.2

 * MicroK8s passes 9 million downloads. Thank you to all our contributors!

     https://microk8s.io/

11 updates can be installed immediately.
0 of these updates are security updates.
To see these additional updates run: apt list --upgradable



The programs included with the Ubuntu system are free software;
the exact distribution terms for each program are described in the
individual files in /usr/share/doc/*/copyright.

Ubuntu comes with ABSOLUTELY NO WARRANTY, to the extent permitted by
applicable law.

WARNING: Your password has expired.
You must change your password now and login again!
Changing password for ubuntu.
Current password:
New password:
Retype new password:
passwd: password updated successfully
Connection to 192.168.4.2 closed.

パスワードを変えると自動的に再起動するので,再度 ssh でログインします.
これで Raspberry Pi のヘッドレス起動成功です!

ホスト名でログインできるようにする

毎回ipアドレスを検索するのは面倒なので,ホスト名でログインできるようにします.

ssh で Raspberry Pi にログインした状態で,いつも通りライブラリを更新します.

sudo apt-get update
sudo apt-get upgrade

avahi-daemon をインストールします.

sudo apt-get install avahi-daemon

これで再起動すれば,次回からホスト名 (デフォルトは ubuntu)でログインできるようになります.
